RS232 USB2.0 Gps Inertial Navigation System Underwater Pipeline Detecting

Name: RS232 USB20 Gps Inertial Navigation System Underwater Pipeline Detecting
Brand: THUNDSEA
Price: 1 USD

Brand Name : THUNDSEA

Model Number : PTK- 20 Inertial Measuring System for Pipeline Surveying

Certification : CCS

Place of Origin : Qingdao

MOQ : one set

Payment Terms : L/C, T/T

Supply Ability : 30 set per month

Delivery Time : 15 Days

Packaging Details : carton box

Attitude : 0.05deg,1σ

Heading : 0.5deg,1σ

Storage : ≥32G

Accuracy : 1.8m~3.6m over 1km~2km aiding

Veiocity : ±400deg/s

Acceleration : ±20g

Vibration : 0.04g²/hz@20~2000hz

Shock : 30g@6ms,keep accuracy;50g@11ms,survival

Size : φ80×190mm

Power supply : 24V DC

Weight : ≤2.5kg

Power Consumption : ≤15W

Interface : RS232,USB

Contact Now

RS232 USB2.0 Gps Inertial Navigation System Underwater Pipeline Detecting

Overeview

Based on Inertial Navigation Technology and FOG technology, PTK-20 consists of three fiber optic gyroscopes, three flexible accelerometers and electronic devices for signal

processing. The gyroscopes are used to determine the attitude and heading and accelerometers are used to determine translational motion.

PTK-20 contains fiber optical gyroscopes (0.003-0.5 degree/h). Different precision optical gyroscopes can be chosen according to different applications. We can customize

different accuracy and size on basis of customers‘ requirements.

The pipelines must be checked regularly for maintenance purpose with help of effective inspection tools searching for damage such as deformation, corrosion or leaks. With the help of our PTK-20 Inertial Measuring system, it is easy and precise to determine the exact location of the inspection tools. Attribute to its high accuracy, the scope of necessary repairs has been largely reduced, resulting in much

less repair costs.

Technical Data

Performance	Alignment	5min
	Attitude	0.05deg,1σ
	Heading	0.5deg,1σ
Storage	Storage	≥32G
Storage	Reading Speed	USB2.0,rate≥35Mb/s
Accuracy	1.8m~3.6m over 1km~2km aiding
Measuring Range	Veiocity	±400deg/s
Measuring Range	Acceleration	±20g
Environment	Working TEMP	﹣40℃~70℃
	Storage TEMP	﹣55℃~85℃
	Vibration	0.04g²/hz@20~2000hz
	Shock	30g@6ms,keep accuracy;50g@11ms,survival
SWaP	Size	φ80×190mm
	Power supply	24V DC
	Weight	≤2.5kg
	Power Consumption	≤15W
	Interface	RS232,USB

RS232 USB2.0 Gps Inertial Navigation System Underwater Pipeline Detecting
